It has a three dimensional
straightening mechanism based on the principle of fatigue
stress with the help of spindle. The machine is specially
designed for maintenance free operation and smooth working.
The following data will provide you a better idea of
the machine. |
|
Specifications |
|
|
|
|
TECHNICAL DETAIL |
|
|
| §
Wire |
2 - 5 mm |
|
| §
Speed |
30m / min |
|
| §
Power Consumption |
4 H.P |
|
| §
Weight |
510 KG |
|
| §
Applicability |
Plain Wire |
|
|
|
|
|
SALIENT FEATURES |
| §
Maintenance free design |
| §
Closed universal box conveyor |
| §
Individual motor for each motion thus easily
controllable |
| §
After sales service |
| §
Anti vibration mountings to isolate spindle vibrations |
| §
Close fit tolerances |
| §
Chain drive for pulling roller |
| §
Automatic wire oiling system (optional) |
| §
Spindle rpm upto 5000 rpm for better straightening |
| §
Pneumatic pulling system |
| §
High speed cut release |
| §
Aesthetic look to suite your premises. |
|
|
|
|
